Chemical Components of 904L Stainless Steel Seamless Pipe
GB | ASTM | DIN | Chemical Component (%) |
C | Si | Mn | P | S | Ni | Cr | Mo | Cu | N |
0Cr20Ni25Mo4.5Cu | 904L | 1.4539 | ≦0.03 | ≦1.00 | ≦2.00 | ≦0.035 | ≦0.030 | 23.00-28.00 | 18.00-23.00 | 5-6 | 1.0-2.0 | ≦0.1 |
Outer Diameter: 6mm~720mm ; 1/8’’~36’’
Wall thickness: 0.89mm~60mm
Tolerance:+/-0.05~ +/-0.02
Production Technology of 904L Stainless Steel Seamless Pipe
1. Drawing: Drawing the rolled blank through the die hole into a section to reduce the increase in length
Rolling: the blank is passed through the gap of a pair of rotating
2. Rollers: Due to the compression of the rollers, the material section is reduced and the length is increased. This is a common way to produce steel tube
3. Forging: To change the blank into the desired shape and size by using the reciprocating impact force of the hammer or the pressure of the press
4. Extrusion: The blank is placed in a closed extrusion container with pressure applied at one end to extrude the blank from the specified die hole to obtain different shapes and sizes
Features and Application of 904L Stainless Steel Seamless Pipe
904L Stainless Steel Seamless Pipe is a low carbon, high alloyed austenitic stainless steel designed for harsh corrosion conditions. It has better corrosion resistance than 316L and 317L, and combines price and performance, with high-cost performance. Due to the addition of 1.5% copper, it has excellent corrosion resistance for reducing acids such as sulfuric acid and phosphoric acid. 904L Stainless Steel Seamless Pipe is mainly used in Oil&Gas, Food & Drug, Medical, Transportation, Construction, and other fields.
Image details of Seamless Pipe products
Factory Details of Stainless Pipe
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2008,sell to Mid East(25.00%),South America(15.00%),Southeast Asia(15.00%),North America(10.00%),Africa(10.00%),Domestic Market(10.00%),Eastern Europe(5.00%),Oceania(5.00%),South Asia(5.00%). There is a total of about 31-50 people in our office.
2. how can we guarantee the quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3. what can you buy from us?
Stainless Steel Plate/Stainless Steel Pipe/Stainless Steel Profile, Steel Plate/Steel Pipe
